LENOVO ThinkSystem ST650 V3

Lenovo ThinkSystem ST650 V3 – 4U Rack Server

The Lenovo ThinkSystem ST650 V3 is a powerful and scalable 4U rack server designed for enterprise workloads, virtualization, storage expansion, and mission‑critical applications. Equipped with Intel® Xeon® Silver processors, DDR5 ECC memory, redundant power, and broad RAID support, it delivers high reliability and performance for modern IT environments.

Highlights

• ⚙️ Intel® Xeon Silver 4510 (12 cores, 2.4 GHz, up to 4.1 GHz boost)
• 🧠 32 GB DDR5‑SDRAM ECC (max. 4 TB)
• 💾 8× internal 2.5" drive bays, hot‑swap capable
• 📦 RAID support: 0 / 1 / 10 / JBOD (Controller 940‑8i)
• 🌐 Broadcom 57416 10GbE LAN (2× RJ‑45)
• 🔌 Redundant PSU support, 1100 W installed
• 🔒 TPM 2.0 + XClarity Controller Platinum
• ❄️ Operating temperature 5–45°C, 80 PLUS Titanium PSU

Technical Specifications

Processor

• Processor family: Intel® Xeon Silver
• Model: Xeon Silver 4510
• Base frequency: 2.4 GHz
• Boost frequency: 4.1 GHz
• Cores: 12
• Cache: 30 MB
• Generation: Intel Xeon Scalable 4th Gen
• Installed processors: 1

Memory

• Installed: 32 GB DDR5‑SDRAM ECC
• Layout: 1 × 32 GB
• Maximum capacity: 4 TB

Storage

• Internal bays: 8 × 2.5"
• Hot‑swap: Yes
• Max storage capacity: 320 TB
• Supported interfaces: SAS

RAID

• RAID support: Yes
• RAID levels: 0, 1, 10, JBOD
• Supported controller: 940‑8i

Networking

• LAN controller: Broadcom 57416
• Ethernet: 10/100/1000Base‑T(X)
• Ports: 2 × RJ‑45 (10GbE)

Ports & Interfaces

• USB 2.0: 1
• USB 3.2 Gen1 Type‑A: 5
• VGA: 1
• Serial port: 1

Chassis & Design

• Form factor: Rack (4U)
• Color: Black
• Rack‑mountable: Yes
• Unused fan support: Yes

Management & Security

• XClarity Controller Platinum
• TPM 2.0

Operating System Compatibility

• Windows Server 2019 / 2022
• Red Hat Enterprise Linux 8.6 / 8.7 / 9.0 / 9.1
• SUSE Linux Enterprise Server 15 SP4
• Ubuntu 22.04 LTS 64‑bit
• VMware ESXi 7.0 U3 / 8.0 U1

Power

• Installed PSU: 1100 W
• Redundant PSU support: Yes
• 80 PLUS Titanium certified

Environmental

• Operating temperature: 5–45°C
• Storage temperature: –40–60°C
• Operating humidity: 8–90%
• Altitude: 0–3050 m

Dimensions & Weight

• Width: 175 mm
• Depth: 734 mm
• Height: 462 mm
• Weight: 39.1 kg

SKU / EAN

Manufacturer

• Lenovo

Product Datasheets: EN, DE,
